Grade 2 Commercial Pure Titanium Plate Overview
Baoji Yibaite New Materials Technology Co., Ltd. specializes in supplying Grade 2/TA2 industrial pure titanium plates (GR2). The company is located in "China Titanium Valley" - Baoji, and is a high-tech enterprise dedicated to the processing and sales of titanium alloys.
GR2 is known as the "workhorse" of the industrial pure titanium family (typically ≥99.2% titanium), offering an optimal balance of moderate strength, excellent ductility, and superior weldability. This material exhibits exceptional corrosion resistance in highly oxidizing and mildly reducing environments, along with outstanding formability and biocompatibility. Our titanium plates are the preferred materials for chemical processing equipment, heat exchangers, marine engineering, power generation, and medical devices.
Products Description
Optimal strength & ductility
- Titanium purity is ≥ 99.2% with a perfectly balanced oxygen content.
- Tensile strength ≥ 345 MPa (significantly higher than Gr1), providing excellent load-bearing capacity while maintaining good elongation(≥ 20%)and formability.
Outstanding corrosion resistance
- Exceptional resistance to seawater, marine atmospheres, wet chlorides, nitric acid, and various organic acids.
- Widely recognized as the standard material for highly corrosive chemical processing environments.
Superior strength-to-weight ratio
- With a density of only 4.51 g/cm³ (about 60% of steel), it offers an exceptional strength-to-weight ratio.
- Ideal for reducing structure weight while maintaining structural integrity and high mechanical reliability.
Excellent weldability & fabrication
- Highly adaptable to standard cold/hot rolling, stamping, and machining processes.
- Exhibits excellent weldability via TIG, MIG, and plasma welding, ensuring strong, leak-free joints in pressure vessels and piping systems.
Medical & food grade compliance
- Non-toxic, non-magnetic, and highly biocompatible.
- Complies with ASTM F67 / ISO 5832-2 and ISO 13485 standards.
- Widely used in medical implants, bone plates, pharmaceuticals, and high-end food processing equipment.
Certified & reliable quality
- Manufactured in our 2,100m2 modern plant in "China Titanium Valley" using advanced processing equipment.
- Strictly certified under ISO 9001 and fully tested to ensure 100% compliance with international standards (ASTM B265 / ASME SB265).
Specifications
| Material Grade | Standard | Thickness | Width | Length | Surface Treatment | Process |
| GR2 (Grade 2 / TA2, UNS R50400) | ASTM B265, ASME SB265, ASTM F67 (Medical), AMS 4911, JIS H4600 TP340C | 0.3mm – 60mm | 100mm – 3000mm | 100mm – 6000mm | Chemical cleaning, polishing, wire drawing, sandblasting | Cold rolled (for thin sheets), Hot rolled (for thick plates) |
Application Fields
GR2 titianum plates are widely applied in:
-
Chemical and petrochemical processing:Pressure vessels, reactors, storage tanks, and heavy-duty piping systems.
-
Power generation and industrial heat exchangers: Shell and tube heat exchangers, plate heat exchangers, condensers for power plants, and evaporators.
-
Marine engineering and seawater desalination:Desalination units rely on these plates. Offshore drilling platforms use them too. Ship hulls, marine valves, and piping at coastal power stations also contain GR2 titanium.
-
Medical and pharmaceutical equipment:Medical implants are made from GR2 titanium. Bone fixation plates and orthopedic screws as well. In pharmaceutical production, reaction tanks use these plates. Food processing machinery also needs them, especially where sanitation matters.
-
Aerospace and advanced manufacturing: Sputtering target materials come from GR2 plates. Battery components and fuel cell electrodes are other examples.
-
New energy and electrochemistry: Hydrogen fuel cell bipolar plates use this material. So do MMO anode substrates. Battery current collectors and high-purity sputtering targets also fall into this category.
Source factory of China Titanium Valley
Complete certifications
Strict quality control system
One-stop customized service
Global delivery service
FAQ
Q: Are you a manufacturer or a trading company?
A: We are a professional and experienced titanium products manufacturer in China.
Q: Can you provide customized processing?
A: Yes. Baoji Yibaite supports cutting, bending, stamping, CNC machining, and deep drawing according to customer drawings.
Q: What is the delivery time?
A: Regular size in stock within 3–7 days; customized production about 10–15 working days.
Q: What standards do your GR1 titanium plates comply with?
A: Our GR2 titanium plates strictly comply with international standards including ASTM B265, ASME SB265, ASTM F67 (for medical applications), AMS 4911, and JIS H4600. We provide a full Material Test Certificate (MTC) compliant with EN 10204 3.1, which includes traceable chemical composition and mechanical property testing.
Q: What surface finishes are available?
A: Pickled surface, polished, brushed, sandblasted, and mirror finish are all optional.
